B.Vacuum Molding Machine VL-A24

B.Vacuum Molding Machine VL-A24 Panel Dimension:

1. Width: 254-610 mm
2. Length: 254-610 mm
3. Thickness: 0.05-2 mm (Without Copper: Single Thickness ≥ 1/3 oz)

Lamination Process:

1. Conveyor Speed: 1-5 M/min adjustable
2. Vacuum: 20-0.2 Torr
3. Pressure: 0-5 kg/cm2
4. Heater: 3.4 KW x 2

External Dimension / Weight: L 3900 x W 1480 x H 2368 (mm) & 2160 kg Utilities:

1. Power: AC220V 3Φ 60HZ 11KVA 29A & AC380V 3Φ 50HZ 11 KVA
2. Compressed Air: 6 kgf/cm2

Temperature Controller: PID Control + S.S.R driving Operation Control: PLC + Touch Screen Monochrome LCD Display Exhaust: Φ4" x 1 : 5 CMM
